STMicroelectronics STEVAL-CCA044V1, Dual BTL Class-D Audio Amplifier Demonstration Board Demonstration Board for 160
- RS Stock No.:
- 196-2543
- Mfr. Part No.:
- STEVAL-CCA044V1
- Brand:
- STMicroelectronics
3 In stock for delivery within 7 working day(s)
Added
Price (ex. GST) Each
$157.59
(exc. GST)
$181.23
(inc. GST)
| Units | Per unit |
| 1 + | $157.59 |
- RS Stock No.:
- 196-2543
- Mfr. Part No.:
- STEVAL-CCA044V1
- Brand:
- STMicroelectronics
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- IT
Product Details
The STEVAL-CCA044V1 demonstration board is
designed for the TDA7498E high power dual BTL
class-D audio amplifier.
Thanks to its high efficiency, the device
assembled in the PSSO36 (slug-down) package
is capable of dissipating heat without a heatsink.
Jumpers on the board allow the configuration of
the amplifier in order to verify all the features as
single-ended or differential input, fixed gain
settings.
Microswitches are also provided to enable the
standby and mute functions.
designed for the TDA7498E high power dual BTL
class-D audio amplifier.
Thanks to its high efficiency, the device
assembled in the PSSO36 (slug-down) package
is capable of dissipating heat without a heatsink.
Jumpers on the board allow the configuration of
the amplifier in order to verify all the features as
single-ended or differential input, fixed gain
settings.
Microswitches are also provided to enable the
standby and mute functions.
Specifications
Attribute | Value |
|---|---|
| Kit Classification | Demonstration Board |
| For Use With | 160 W+160 W Dual BTL Class-D Audio Amplifier |
| Kit Name | Dual BTL Class-D Audio Amplifier Demonstration Board |
