RS PRO OA172S Series Axial Fan, 230 V ac, 383.9 m³/h, 29 W, 120 mA Max, IP55 150 mm, 172 mm, 51 mm

View all Axial Fans
Bulk discount available

Subtotal (1 unit)*

$93.05

(exc. GST)

$107.01

(inc. GST)

Add to Basket
Select or type quantity
In Stock
  • 29 unit(s) ready to ship from another location
  • Plus 20 unit(s) shipping from 25 August 2026
  • Plus 20 unit(s) shipping from 08 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4$93.05
5 +$76.59

*price indicative

RS Stock No.:
175-9789
Distrelec Article No.:
304-18-144
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Product Type

Axial Fan

Supply Voltage

230 V ac

Power Consumption

29W

Maximum Current

120mA

Air Flow

383.9m³/h

Noise Level

58dB

Fan Speed

3400rpm

Direction of Curve

Backward

Terminal Type

Wire

Fan Frame Type

Round

Bearing Type

Ball

Fan Frame Size

172 mm

Depth

51mm

Standards/Approvals

RoHS

Height

150mm

Series

OA172S

Width

172 mm

IP Rating

IP55

COO (Country of Origin):
TW

RS PRO AC Axial Fan 383.9 m³/h, 230 V


Need a high-powered fan that won't create excessive noise in your workplace? Choose this AC axial fan from RS PRO. It uses circular blades to increase the airflow around your mechanical equipment to keep it running smoothly.

This fan operates at a noise level of just 58 decibels (dB), on a par with normal conversation, so it won't contribute to a loud or distracting work environment. Its frame is made of sturdy die-cast aluminium that keeps the fan securely fixed in place once installed.

The fan operates in temperatures of up to +80°C, meaning it can withstand the high heat caused by motors in constant use. It has an Ingress Protection (IP) rating of IP55, indicating it's sealed against water jets and harmful dust.

Features and Benefits


• AC operation

• Airflow of 383.9 m³/h

• Dimensions of 150 (height) x 172 (width) x 51 mm (depth)

• Backward direction of curve

• Round fan housing shape

• Fan speed of 3400 rpm

• Ingress Protection (IP) rating of IP55

• Maximum current of 120 mA

• Noise level of 58 dB

• Power consumption of 29 W

• AC capacitor drive motor

• Class B insulation

• Dual ball bearing

• Thermally protected motor

• Static pressure of 0.79 in H2O

• Supply voltage of 230 V AC

• Lead wire termination type

The RS PRO AC Axial Fan uses electrical machinery to cool it down and keep it running smoothly. It has frame made of aluminium diecast and once installed it offers the perfect cooling solution with reliability and quality.

Capacitor Drive Motor

Dual Ball Bearing

Impedance Protected Motor
