Fluke 1777 Power Quality Analyser, 3-Phase, 6000A Max, 1000V dc Max
- RS Stock No.:
- 232-0535
- Mfr. Part No.:
- FLUKE-1777
- Brand:
- Fluke
Stock check temporarily unavailable - call for stock availability
Added
Price (ex. GST) Each
$20,896.70
(exc. GST)
$24,031.20
(inc. GST)
| Units | Per unit |
| 1 + | $20,896.70 |
- RS Stock No.:
- 232-0535
- Mfr. Part No.:
- FLUKE-1777
- Brand:
- Fluke
Legislation and Compliance
- COO (Country of Origin):
- RO
Product Details
FLUKE Power Quality Analyser, 6000A Max Current Measurement, 1000V DC Maximum Voltage - 1770 Series - FLUKE-1777
Want to keep your electrical system ahead of the curve? Choose this power quality analyser from FLUKE to monitor voltage signals and detect electrical disturbances. It's a 3-phase unit with 4 inputs, so it can measure multiple signals simultaneously to capture a clear picture of your system. Automatic measurements and a user-friendly interface make this device a breeze to operate. To boost protection, it catches up to 8kV high-speed voltage transients in the act before they become an issue. A broad operating temperature range between -10°C and 50°C means this is a suitable option for tough industrial conditions.
Features & Benefits
• Voltage measurement of ±0.1% for precise readings
• USB, WiFi, LTE, wired Ethernet, or USB cable connectivity to easily download data
• Power can be drawn directly from the measurement circuit to eliminate the hassle of extra cords
• Kensington lock slot prevents unauthorised access
• USB, WiFi, LTE, wired Ethernet, or USB cable connectivity to easily download data
• Power can be drawn directly from the measurement circuit to eliminate the hassle of extra cords
• Kensington lock slot prevents unauthorised access
Applications
• Energy surveys
• Data centres
• Renewable energy systems
• Data centres
• Renewable energy systems
What size is this analyser?
It has compact dimensions of 28 (L) x 19 (W) x 6.2cm (H), so it's easy to handle.
How much does this analyser weigh?
As it weighs just 2.1kg, to can carry it with you in the field.
Specifications
Attribute | Value |
|---|---|
| Absolute Maximum Current Measurement | 6000A |
| Absolute Maximum Power Measurement | 1500mW |
| Number of Phases | 3 |
| Maximum Voltage | 1000V dc |
| Best Voltage Measurement Accuracy | ±0.1 % |
| Measurement Type | Current, Power, Voltage |
| Measurement Standards | EN50160 |
| Interface Type | Bluetooth, USB, Wireless |
| Power Source | Battery |
| Battery Type | Li-Ion |
| Model Number p | 1777 |
| Minimum Frequency | 50 Hz |
| Dimensions | 28 x 19 x 6.2cm |
| Maximum Operating Temperature | +50°C |
| Weight | 2.1kg |
| Length | 280mm |
| Width | 190mm |
| Maximum Frequency | 60Hz |
| Minimum Operating Temperature | -10°C |
| Height | 62mm |
