- RS Stock No.:
- 181-5116
- Brand:
- RS PRO
1000 In stock for delivery within 7 working day(s)
Added
Price (ex. GST) Each (In a Bag of 500)
$0.758
(exc. GST)
$0.872
(inc. GST)
Units | Per unit | Per Bag* |
500 - 500 | $0.758 | $379.00 |
1000 - 1500 | $0.739 | $369.50 |
2000 + | $0.728 | $364.00 |
*price indicative |
- RS Stock No.:
- 181-5116
- Brand:
- RS PRO
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
RS PRO Electrolytic Capacitor
The RS PRO 1000μF through-hole mount electrolytic capacitor has a voltage rating of 25VDC and leakage current of 2μA. This low impedance capacitor has dimensions of 10mm x 25mm (diameter x length). This capacitor is designed with a safety vent construction.
Features and Benefits
Tolerance: ±20%
Lifetime: 1000 hours
Ripple current: 1580mA
Dissipation factor: 14%
Lead pitch: 5mm
Load life: 3000∼10000 hours at 150 °C
Impedance: 0.05ohm
Operating temperature ranging between -40°C and 105°C
Lifetime: 1000 hours
Ripple current: 1580mA
Dissipation factor: 14%
Lead pitch: 5mm
Load life: 3000∼10000 hours at 150 °C
Impedance: 0.05ohm
Operating temperature ranging between -40°C and 105°C
Applications
Used in communication equipment
Switching power supply
Industrial measuring instruments
Switching power supply
Industrial measuring instruments
Certifications
ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007
BS EN 61340-5-1:2007
Specifications
Attribute | Value |
---|---|
Capacitance | 1000µF |
Voltage | 25V dc |
Mounting Type | Radial, Through Hole |
Technology | Aluminium Electrolytic |
Dimensions | 10 (Dia.) x 25mm |
Height | 25mm |
Minimum Operating Temperature | -40°C |
Diameter | 10mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 5mm |
Lifetime | 1000h |
Tolerance | ±20% |
Ripple Current | 1.58A |
Leakage Current | 2 μA |
Dissipation Factor | 14% |
