Wurth Elektronik 2.4 V RGB LED 2012 Surface WL-SFCD 150080M153000
- RS Stock No.:
- 176-6132
- Mfr. Part No.:
- 150080M153000
- Brand:
- Wurth Elektronik
This image is representative of the product range
Bulk discount available
View bulk pricing optionsSubtotal (1 pack of 25 units)*
$21.30
(exc. GST)
$24.50
(inc. GST)
Spend over $80.00 ex GST for FREE delivery
In Stock
- 75 unit(s) ready to ship from another location
- Plus 1,400 unit(s) shipping from 23 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 25 - 475 | $0.852 | $21.30 |
| 500 - 975 | $0.836 | $20.90 |
| 1000 + | $0.821 | $20.53 |
*price indicative
- RS Stock No.:
- 176-6132
- Mfr. Part No.:
- 150080M153000
- Brand:
- Wurth Elektronik
Specifications
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | LED | |
| LED Colour | RGB | |
| Package Type | 2012 | |
| Maximum Forward Current | 60mA | |
| Mount Type | Surface | |
| Packaging | Tape & Reel | |
| Number of LEDs | 3 | |
| Maximum Power Dissipation | 48mW | |
| Forward Voltage | 2.4V | |
| Number of Pins | 4 | |
| Viewing Angle | 120 ° | |
| Lens Dimensions | 2 x 1.3 x 0.5 mm | |
| Lens Shape | Rectangular | |
| Standards/Approvals | RoHS, IEC 61249-2-21, REACH, JEDEC JS709B | |
| Dominant Wavelength | 470nm, 525nm, 624nm | |
| Lens Finish | Diffused | |
| Series | WL-SFCD | |
| Lens Colour | Clear | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type LED | ||
LED Colour RGB | ||
Package Type 2012 | ||
Maximum Forward Current 60mA | ||
Mount Type Surface | ||
Packaging Tape & Reel | ||
Number of LEDs 3 | ||
Maximum Power Dissipation 48mW | ||
Forward Voltage 2.4V | ||
Number of Pins 4 | ||
Viewing Angle 120 ° | ||
Lens Dimensions 2 x 1.3 x 0.5 mm | ||
Lens Shape Rectangular | ||
Standards/Approvals RoHS, IEC 61249-2-21, REACH, JEDEC JS709B | ||
Dominant Wavelength 470nm, 525nm, 624nm | ||
Lens Finish Diffused | ||
Series WL-SFCD | ||
Lens Colour Clear | ||
Automotive Standard No | ||
- COO (Country of Origin):
- TW
Characteristics
High efficiency
Low power consumption
Diffused optics
Red/Green/Blue color combination
Compatible with reflow soldering
Standard Soldering Pad
RGB
Wide viewing angle
Applications
Backlighting
Status indicator
Front panel indicator
Office automation, home appliances, industrial equipment
Backlighting for keypad, symbol and switch button
Consumer electronics
Safety and security
General lighting
