Carlo Gavazzi RGC1P DIN Rail, Panel Power Controller AC 250V Analogue

RS Stock No.:: 125-0691
Distrelec Article No.:: 301-65-402
Mfr. Part No.:: RGC1P23V30ED
Brand:: Carlo Gavazzi

Carlo Gavazzi RGC1P DIN Rail, Panel Power Controller AC 250V Analogue

Subtotal (1 unit)*

$480.25

(exc. GST)

$552.29

(inc. GST)

Spend over $80.00 ex GST for FREE delivery

In Stock

41 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	$480.25

*price indicative

RS Stock No.:: 125-0691
Distrelec Article No.:: 301-65-402
Mfr. Part No.:: RGC1P23V30ED
Brand:: Carlo Gavazzi

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Carlo Gavazzi
	Output Type	AC
	Product Type	Power Controller
	Maximum Current	63A
	Maximum Operating Temperature	70°C
	Minimum Operating Temperature	-40°C
	Terminal Type	Screw
	Control Type	Analogue
	Maximum Supply Voltage	250V
	Firing Mode	Soft Starting, X16, X4, Advanced Full Cycle, Phase Angle
	Controlled Phases	1
	Display Type	LED
	Maximum Voltage	660V
	Length	35.8mm
	IP Rating	IP20
	Width	70mm
	Standards/Approvals	CSA 22.2 No.14-13, EN50155, EN 60947-4-3, EN61373, RoHS (2011/65/EU), UL508
	Series	RGC1P
	Mount Type	DIN Rail, Panel
	Input Type	Analogue
	Panel Depth	99mm

	Select all
	Brand Carlo Gavazzi
	Output Type AC
	Product Type Power Controller
	Maximum Current 63A
	Maximum Operating Temperature 70°C
	Minimum Operating Temperature -40°C
	Terminal Type Screw
	Control Type Analogue
	Maximum Supply Voltage 250V
	Firing Mode Soft Starting, X16, X4, Advanced Full Cycle, Phase Angle
	Controlled Phases 1
	Display Type LED
	Maximum Voltage 660V
	Length 35.8mm
	IP Rating IP20
	Width 70mm
	Standards/Approvals CSA 22.2 No.14-13, EN50155, EN 60947-4-3, EN61373, RoHS (2011/65/EU), UL508
	Series RGC1P
	Mount Type DIN Rail, Panel
	Input Type Analogue
	Panel Depth 99mm

Datasheet

COO (Country of Origin):: MT

Carlo Gavazzi SSR Power Controller

The Carlo Gavazzi RGC1P series SSR power controller has a solid-state contactor supplied with the integrated heatsink. It required analogue input and a current rating of 30A. It is used to control the output power of single-phase loads with an analogue control input. It has selectable switching modes regulated with a knob on the front of the controller. This also allows phase angle control, full-cycle control, advanced full-cycle control, and soft starting. The output of the power controllers is protected against overvoltages by an integrated varistor across the output.

Features and Benefits

100kA short circuit current rating

1-pole analogue switching AC solid-state contactors

2 front LEDs indicate the status of load and control

Control inputs: 4-20 mA, 0V-5V, 1V-5V, 0V-10V, external potentiometer

DIN-rail or panel mounting

Integrated heatsink

Integrated varistor protection on output

Rated operation current up to 63AAC

Rated operational voltage up to 660VAC

Selectable modes of operation are Phase angle, full-cycle x1, x4 or x16, advanced full-cycle specific for short wave infrared heaters and soft starting for limiting inrush current of loads having a high-temperature coefficient
