Circular Connectors

Circular connectors are made of multi-pin interconnects paired with cylindrical housing containing a contact interface. They can be made of plastic, metal, or a combination of both. Like most kinds of electrical connectors, their function is to enable a secure signal and current transmission by pairing a male half (the pins) to a female receptacle (the housing).

What are the benefits of circular connectors?

Circular connectors have increasingly been used in electronics due to their advantages over their rectangular counterparts. Because of their structure, one of their immediate benefits is the fact they can group several contacts in a compact space, enabling a space-saving and simple solution to disconnect and reconnect cables from their devices. However, they are also particularly convenient for:

  • Housing different kinds of contacts
  • Allowing contacts with different currents thanks to the extensive range of allowable voltages
  • Sealing hermetically where an absolute integer connection is needed
  • Conveying a strong mechanical performance in environmentally demanding applications

What are circular connectors used for?

Depending on their design and layout (threaded, push-pull, as well as many otherS), their use might be more suitable to certain applications rather than others, but in general the advantages brought by a circular connector make their range of applications very broad, from data and communication to military and aerospace industries. The high performance required by harsh industrial environments makes it necessary for the circular connector to be rugged and shielded against EMI to avoid any damage from water contamination, dirt, extreme temperature or vibration.

How do circular connectors work?

Different components are available to maximise the function of your circular connector, and our range includes:

Available from recognised worldwide brands, such as Amphenol, Deutsch, TE Connectivity and our own RS Pro.

Guides & Articles

article1_image

In our comprehensive guide we look at what din rails are, what they’re used for, as well as the different types that are available on the market.

article1_image

In our definitive guide, we look at what HDMI Connectors are, what they’re used for, as well as the different types that are available.

Related Products
From Lemo, this FGG 1B class connector is ...
Description:
From Lemo, this FGG 1B class connector is well suited for most applications and features a 'push-pull' latching mechanism for easy and secure connection. With a rugged design, this connector is not only manufactured with precision quality in mind, but ...
TE Connectivity SLC Series MIL-C-38999 Spin-Lock saddle clamp ...
Description:
TE Connectivity SLC Series MIL-C-38999 Spin-Lock saddle clamp variable angle backshell cable adapters that enable braided cable shield to be terminated to a Raychem code 40 D38999 connector (see note) in a straight ,45° or 90° orientation as well as ...
A comprehensive range of connector conduit adaptors in ...
Description:
A comprehensive range of connector conduit adaptors in straight and 90 degree versions suitable for use with the ABCIRP range of MIL-C-5015 derived square flange receptacle mount connectors and cable mount plug connectors. Thread suitable for grounding band application. Machined ...
The NL series of industrial connectors offers a ...
Description:
The NL series of industrial connectors offers a standard configuration which is intermatable with MIL-C-38999 Series III connectors. The connectors are fitted with a first make last break earth contact and metal backshell which offers excellent shielding capabilities. Scoop-proof design ...
